How To Put A Ball Hitch On a Lawn Mower

Upgraded Home Team
by Upgraded Home Team

you want to make your lawnmower even more versatile and hard-working, mounting a ball hitch can be a great idea. However, before you begin, you need to know how to install it.

To put a ball hitch on a lawn mower, begin by placing it in park mode and disconnecting the power. Next, attach the brace arms, and follow with the hitch body. Make sure your hitch is properly assembled if it requires any mounting before attaching it to your lawn mower.

Depending on the hitch you choose, this process may be relatively simple and straightforward. In this article, we’re going to outline the specific steps so that you can feel confident with your new hitch.

Step by Step Guide for Installing a Ball Hitch

Step One: Know Your Mower’s Towing Capacity

Before you can start browsing different hitches to put on your lawnmower, you need to know its towing capacity. This number should be listed in the owner’s manual. However, if you don’t have a manual, an excellent rule to follow is that you shouldn’t try to tow anything heavier than the lawnmower itself. So, if the machine is 1500 pounds, that is your towing limit.

That being said, we highly recommend giving yourself a buffer, just to be safe. In this case, you should limit your towing capacity to 1300 pounds. Doing this can save a lot of wear and tear on the engine, and may prevent stall-outs and other mechanical problems.

Step Two: Find a Suitable Ball Hitch

Fortunately, there are many different trailer hitch options for lawn mowers and tractors. Most of these hitches are semi-universal, meaning that you don’t have to make sure that your mower is compatible. However, not all hitches are as easy to install, so pay attention to the installation instructions. Other elements to pay attention to include:

Ball Size: Since lawnmowers aren’t designed for heavy loads, most hitches use a one-inch ball. However, some may be bigger than that. Once you determine what you will be towing, you can choose the correct ball size.

Height: Some hitches will sit higher on the lawnmower so that it’s easier to hook up. However, in some cases, you may prefer to have the hitch sit lower on the machine. Again, you’ll have to figure out what you plan on towing with your mower to determine the best height.

Assembly: Most hitch models don’t require assembly, but some of them do. If you’re looking for ease and simplicity, we recommend buying a single-piece hitch.

Step Three: Make Sure You Have the Right Tools

Depending on the hitch you buy, you may or may not have to drill into the back of the mower. For example, a high-hitch has stabilizer bars that have to be attached to the mower itself. Other hitches can simply fix to the mounting hole, which comes standard on most riding lawnmowers. Typically, the only tools you’ll need are a socket wrench set and a drill, but you may need screwdrivers and a hammer. Be sure to read any hitch installation instructions before starting so that you aren’t left empty-handed.

Step Four: Assemble the Hitch

If your ball hitch has mounting bars, you’ll need to attach them before mounting it to the mower. Fortunately, these products come with all of the bolts and washers necessary, so the process is relatively straightforward.

Step Five: Attach the Hitch to the Mower

Thankfully, your riding lawn mower should have a mounting bracket on the back, so all you have to do is attach the hitch with bolts and nuts. However, in some cases, you might have to drill into the metal to put brackets. If that is the case, be sure to check if there are any critical components where you will have to drill.

Ideally, there will be space behind the metal to insert the bolts without any problems. No matter what, be sure to follow the hitch mounting instructions, as well as the user manual for your lawnmower.

Step Six: Do a Test Run

Once the hitch is in place, we recommend hauling something relatively light to make sure that it won’t come loose. This way, you can make any necessary adjustments right away, instead of discovering a problem later on. For example, you don’t want to attach a trailer or wood chipper and have it ripped off by accident.

Safety Precautions When Attaching a Ball Hitch

Overall, the installation process is safe and straightforward, particularly if you don’t have to do any drilling. If you do need to drill into the metal, we recommend wearing safety goggles, just in case. Sometimes, small fragments of metal may fling into your eyes, which can be damaging and potentially blinding.

Another thing to do is work on a flat, level surface. We recommend putting wood blocks or tire chocks behind the wheels so that the mower doesn’t rock back and forth too much while you’re working.

Why Attach a Ball Hitch to a Lawnmower?

Having a riding lawnmower makes cutting the grass easy, but once you install a ball hitch, you can make your machine even more productive. Here are a few of the ways you can utilize the hitch to the fullest extent.

  • Haul Wood and Other Debris – If you have a small trailer or flatbed, you can use it with your lawnmower to haul logs and other materials around your property. For example, if you are cutting down or trimming a tree, you can move the branches more efficiently with a mower than by hand.
  • Lawn Vacuums – As you mow the grass, you can collect the clippings with a lawn vacuum. By towing it behind the mower, you can take care of two jobs at once.
  • Aeration – One method of maintaining a lush, green lawn is to aerate it regularly. With a ball hitch on your lawnmower, you can tow a plug aerator with ease.
  • Grading – If you have a dirt or gravel path, a power grader helps smooth out any divots or imperfections. These machines have to be towed, and a lawnmower is closer to the ground than a truck or SUV.
  • Snow/Leaf Blower – During the fall and winter seasons, having a blower can make a huge difference.
  • Seeding – Instead of pushing a grass seeder, you can tow it behind your mower for maximum efficiency.

Related Questions

Will towing wear down my lawnmower engine?

Over time, yes, it can. However, the degree of wear and tear will depend on how much weight your mower is pulling. This is why we recommend hauling less than the maximum capacity to extend the life of your engine.

Is a ball hitch necessary on my lawnmower?

While a hitch can make your mower more practical, it is not necessary. For example, if all you plan to do is cut the grass, you shouldn’t have to haul or town anything. However, if you’re not sure, we suggest installing a hitch anyway. Then, if you do need it later on, your mower is already good to go.
